Summary
| Description |
Side view of an HBR illustrating different rack parameters; ho: approach flow depth, hds: downstream flow depth, Uo: mean upstream approach flow velocity from continuity, Uds: mean downstream flow velocity, hBo: bottom overlay height, hTo: top overlay height, sb: clear bar spacing, tb: bar thickness at thickest point, db: bar depth |
| Author |
Julian Master |
| Source |
Meister, J.; Fuchs, H.; Beck, C.; Albayrak, I.; Boes, R.M. (2020a). Head Losses of Horizontal Bar Racks as Fish Guidance Structures. Water, 12(2): 475. http://dx.doi.org/10.3390/w12020475. |
