File:Numerical modelling bannwil.jpg
Revision as of 09:51, 23 October 2020 by Bendikhansen (talk | contribs) ({{Information |author=Stephan Kammerer |source=VAW of ETH Zurich |description=Exemplary variant study for HPP Bannwil using numerical modelling. Normal (left) and tangential (right) flow velocities at potential FGS positions upstream of the turbine inlets for scenario 1a for fish guidance structures angled at 37° (see FIThydro Deliverable 2.2 for detailed information) }})
Size of this preview: 800 × 344 pixels. Other resolutions: 320 × 138 pixels | 1,524 × 655 pixels.
Original file (1,524 × 655 pixels, file size: 288 KB, MIME type: image/jpeg)
Summary
| Description |
Exemplary variant study for HPP Bannwil using numerical modelling. Normal (left) and tangential (right) flow velocities at potential FGS positions upstream of the turbine inlets for scenario 1a for fish guidance structures angled at 37° (see FIThydro Deliverable 2.2 for detailed information) |
| Author |
Stephan Kammerer |
| Source |
VAW of ETH Zurich |
