Original file ‎(1,372 × 754 pixels, file size: 243 KB, MIME type: image/png)

Description

Water depths (in meters) to the left and water velocities (in m/s) to the right in a section of Mandal river in southern Norway after lowering a weir

Author
Source

Fjeldstad, H.-P., Stickler, M. and Ugedal, O. 2004. Modellering av habitatforbedrende tiltak Mandalselva. SINTEF Technical report.
